Ladder Cable Tray Forming Machine

Ladder-type cable tray is suitable for large-scale power systems and communication networks. Both sides are in the shape of a problem, which is beneficial to heat dissipation and temperature reduction. This equipment produces ladder-type cable tray side panels. Our production line strictly controls every production link to ensure the excellent quality of the product.

  Contact Now
Product Details

Are you looking for a reliable and efficient solution for cable management? Look no further! Our customized cable tray equipment is designed to meet your specific needs, providing a safe and organized way to support and protect your cables. With years of experience in the industry, we understand the importance of a properly installed cable management system. Our customized cable tray equipment offers a wide range of benefits, designed to streamline your cable routing and ensure the longevity of your electrical infrastructure. One of the key advantages of our customized cable tray equipment is its versatility. We offer a variety of sizes, materials, and finishes to choose from, allowing you to find the perfect fit for your project. Whether you need a simple and cost-effective solution or a more robust system for heavy-duty applications, we have the expertise and resources to deliver. Not only is our cable tray equipment customizable, but it also boasts exceptional durability. Our products are made from high-quality materials that are resistant to corrosion, chemicals, and extreme temperatures. This ensures that your cables are protected from external factors and reduces the risk of damage or performance issues. Another benefit of our customized cable tray equipment is its easy installation and maintenance. Our expert team will provide you with detailed instructions and guidance to ensure a hassle-free installation process. Additionally, our cable tray equipment is designed for easy access, making it simple to inspect, repair, or modify your cable layout as needed. At our company, customer satisfaction is our top priority. We take pride in delivering superior products and exceptional customer service. Our team of skilled professionals is dedicated to working closely with you to understand your requirements and provide customized solutions that meet and exceed your expectations

Ladder Cable Tray Forming Machine

Technical Parameters

Serial number

main component




1. 300 type unwinding

2. Passive discharging

3. Bearing capacity 1.5 tons

4. With braking function



Leveling, punching, cutting

One machine

1. Feeding code correcting mechanism (front and reverse lead screw) 4. Leveling up 2 down 3

2. Hydraulic system 1 set 11KW

3. Hydraulic cutting


high speed platform

1. 1 high-speed platform 3. Adjustment of the width of the front and back screw rods

2. Frequency conversion control


Roll forming part

1. Spindle φ60mm, surface hard chrome plated 4. Extended feeding guide

2. 6 rows of forming rollers 5. 1 set of flat surface straightening after forming

3. Roll material: GCr15


Unloading rack

1、1 passive unloading rack


Control cabinet

1. The entire line adopts PLC control and touch screen human-machine interface to realize human-computer interaction.

2. Operation mode: manual/automatic. In the manual state, it can operate as a stand-alone machine for easy maintenance; in the automatic state, it can operate across the entire line; it is equipped with an emergency stop button, making it easy to handle emergencies and ensuring the safety of equipment and operators.
